Automatic Sensor Urinal Flush Valve, Touchless Wall Mounted Toilet Flusher

The equlup Automatic Sensor Urinal Flush Valve is a touchless, wall-mounted fixture designed for commercial and high-traffic residential restrooms. By eliminating the need to physically handle flush levers, it provides an automated sanitation solution suited for public toilets, hotels, hospitals, airports, and standard bathrooms undergoing renovation projects.

Flushing is managed through an intelligent dual-stage routine. When a user enters the detection zone, the valve initiates a quick two-second pre-rinse. After the user steps away, the system calculates usage time to determine water volume, running a secondary rinse for either two seconds for brief visits under ten seconds, or six seconds for longer visits. To prevent stagnant odors when fixtures sit idle, an integrated deodorization cycle automatically flushes the system once every 24 hours.

Built from electroplated brass, the unit provides a sturdy structure engineered for continuous plumbing demands. It features a standard G1/2 (DN15) water inlet and outlet, an operating water pressure requirement of 0.1 to 0.6 MPa, and static power consumption below 60 microamps. The sensing range operates from 15 to 30 centimeters and can automatically adapt, though custom adjustments require a remote control.

Keep in mind that the unit requires a stable water supply within the stated pressure window and operating temperatures between 0.1 and 45 degrees Celsius. While the sensing range is adjustable via remote control, the product specifications do not state whether the remote is included in the package or sold separately, so manual fine-tuning may require extra hardware.

Verdict: This automatic flush valve is a solid choice for facility managers and property owners looking to modernize restrooms with hands-free operation and scheduled rinsing. It works well for commercial upgrades needing dependable brass hardware and automated odor prevention.

• Material: Brass and electroplated finish
• Inlet/Outlet Diameter: G1/2 (DN15)
• Body Dimensions: Approximately 15.5 x 7.3 cm (6.10 x 2.87 inches)
• Pipe Length: Approximately 18.5 cm (7.28 inches)
• Sensing Distance: 15 to 30 cm (remote control adjustable)
• Sensing Duration: 3 seconds
• Water Pressure Range: 0.1 to 0.6 MPa
• Rated Flow: 9 to 15 L per week (at 0.3 MPa)
• Operating Temperature: 0.1 to 45 degrees Celsius
• Ambient Humidity: Less than 95% RH
• Static Power Consumption: Less than 60uA

A great fit if you:

• Manage public, hospital, hotel, or airport restrooms needing touchless hygiene.
• Want an automatic 24-hour flush function to stop odors in low-use urinals.
• Need a standard G1/2 plumbing retrofit with included wall-mounting hardware.
• Prefer solid brass fixtures over all-plastic valve assemblies.

Consider something else if you:

• Have plumbing lines operating outside the 0.1 to 0.6 MPa water pressure range.
• Require guaranteed on-device buttons for sensor distance adjustments without using a remote.

How does the automatic flushing cycle work?
The valve runs an initial two-second rinse when a user steps into the sensor area. Once the user leaves, it flushes again for two seconds if the visit lasted under ten seconds, or for six seconds if the visit exceeded ten seconds.

How does the unit prevent restroom odors during slow periods?
When the urinal has not been used for an extended period, the valve runs an automated flush cycle once every 24 hours to clear the drain and eliminate odors.

What plumbing connection size is required?
The unit uses standard G1/2 (DN15) connections for both the water inlet and outlet, and it operates under water pressure between 0.1 and 0.6 MPa.
